| Specifications |
| LCD Panel | Screen Size | 75 inch |
| Display area | 1650.62mm(H) X 928.9mm(V) |
| Aspect Ratio | 16:09 |
| Pixel Pitch(mm) | 0.4298(H)X0.4298(V) |
| Max Resolution | 3840X2160 |
| Display color | 10Bit, 16.7M |
| Brightness (nits) | 300 cd/m2 |
| Contrast | 5000 : 1 |
| Viewing angle(up/down/left/right) | 178°/178°/178°/178° |
| Response Time | 6ms |
| Onboard interface | Input port | USB 3.0*2, USB 2.0*2, VGA IN*1, AUDIO IN*1, HDMI IN*3, Touch USB*1, Rs232*1 |
| Output port | VGA OUT*1, MIC*1, AV OUT*1, EAR PHONE*1, RF IN*1;SPDIF out*1;RJ45/LAN in out*1 |
| Power | Power supply | AC 220-240V 50/60Hz |
| Maximum power consumption | ≤ 320W (the whole display with PC) |
| Standby power consumption | < 0.5W |
| OSD display | screen Menu language | Chinese/English( Multiple Language Supported) |
| Product and structure size | Machine Body Dimension | 1723(L)X1043.6(H)X99.2(V) MM |
| Net weight | 59kg |
| wall mounted bracket Dimension | 770mm(L)X205mm(H)X35mm(T) |
| VESA fixed hole Dimension | 600mm(H)X400mm(V) |
| Wall mounted screws specifications | 4 pcs(M8 x L25) |
| Package size and weight | Inner Carton Package size | 1875(L) X 1185(H) X 225(V) MM |
| wooden frame Package size | 183(L) X 130(H) X 30(V) CM Per unit |
| Total weight(Include woode frame) | 108Kg |
| Touch screen parameter | Touch style | Infrared Touch screen |
| Touch points | 10 points |
| Touch Max Resolution | 4096 X 4096 |
| Transparency | >90% ; Up to 100% |
| Response speed | <12m |
| Android PCB configuration | CPU | MSD6A658 ARM A53, Quad Core, 1.5GHz |
| RAM | 1GB |
| Built-in storage volume | 8GB |
| OS | Android6.0 |
| OPS PC BOX Configuration | OPS box model | ZXTLCD-OPSW10-I5G4R4S128 |
| CPU | Intel I5 Processor, 4th Generation |
| RAM | 4GB |
| SSD | 128GB |
| Wifi | support |
| OPS supply voltage | 17-21V DC |
| Rated output current | 1.0A - 7.0A |
| Peak output current | 8.0A |
| Rated load power | 135W |
| Support interface type | OPS-C 80-pin blind plug JAE interface which comply with the specification of Intel open pluggable |
| The dimension of OPS box | L196mmXW180mmXH33mm |
| Image resolution | Maxium support 3840*2160p@30Hz output |
| Operating System | Windows 10 system(English testing version) |
